Layer 3
Verify that ping works over ECMP
test_ping_013
No
Verify that IP address can be configured over SVI
test_IP_001
No
Verify that IP address can be configured over routed port
test_IP_002
No
Verify SVI and routed ports can be admin down or up
test_IP_005
No
Verify connected route gets created for the SVI subnet in the ip route table.
test_IP_006
No
Verify IP interface is operational for SVI with LACP portchannel members
test_IP_011
No
Verify ip address can be configured over routed PCH.
test_IP_014
No
Verify BGP AS configuration works properly
test_bgp_001
No
Verify BGP peering happens with nodes in same AS and iBGP neighbor table gets updated properly
test_bgp_002
No
Verify BGP peering happens with nodes in different AS and eBGP neighbor table gets updated properly
test_bgp_003
No
Verify BGP route learning using eBGP with routes injected from IXIA
test_bgp_004
No
Verify BGP route removal using eBGP with routes withdrawn from IXIA
test_bgp_005
No
Verify BGP route relearn over different neighbor when interface is shutdown
test_bgp_006
No
Verify unnumbered functionality with iBGP
test_qual_bgp_001
Yes
Verify unnumbered functionality with eBGP
test_qual_bgp_002
Yes
Verify BGP route redistribution in DUT
test_qual_bgp_003
No
Verify BGP6 functionality
test_qual_bgp_004
No
Verify BGPV6 Functionality in DUT
test_qual_bgp_ebgp_004
No
Verify BGP AS-PATH prepend functionality
test_qual_bgp_007
No
Verify BGP route map match prefix list, access-list deny and permit functionality
test_qual_bgp_008
No
Verify BGP route map match AS-PATH permit and deny functionality
test_qual_bgp_009
No
Verify BGP route map match community list permit and deny functionality
test_qual_bgp_010
No
Verify BGP max MED functionality
test_qual_bgp_011
No
Verify BGP maximum prefix limit per peer functionality
test_qual_bgp_013
No
Verify BGP communities functionality
test_qual_bgp_014
No
Verify BGP regexp match single and multi AS permit & deny action using AS-path access lists
test_qual_bgp_015
No
Verify BGP regexp match any AS permit and deny action using AS-path access lists
test_qual_bgp_016
No
Verify BGP regexp match range of BGP communities functionality
test_qual_bgp_017
No
Verify BGP peering working with BGP listen range
test_qual_bgp_019
No
Verify VRF functionality
test_qual_vrf
Yes
Verify VLAN 1 support for Host connectivity
test_qual_vlan1
Yes
Verify IPV6 neighbor discovery
test_qual_ipv6_neighbor
No
Verify L3 DROP ACL functionality with matching source IP and source port
test_acl_001
No
Verify L3 DROP ACL functionality with matching destination IP and destination port
test_acl_002
No
Verify L3 DROP ACL functionality with matching SIP, DIP, SPORT, DPORT
test_acl_003
No
Verify L3 DROP ACL with ACL rule having subnet mask
test_acl_004
No
Verify L3 DROP ACL est acl rule with protocol = TCP
test_acl_005
No
Verify L3 DROP ACL - Test acl rule with protocol = UDP
test_acl_006
No
Verify L3 PERMIT ACL functionality with matching source IP and source port
test_acl_007
No
Verify L3 PERMIT ACL functionality with matching destination IP and destination port
test_acl_008
No
Verify L3 PERMIT ACL functionality with matching SIP, DIP, SPORT, DPORT
test_acl_009
No
Verify L3 PERMIT ACL with ACL rule having subnet mask
test_acl_010
No
Verify L3 PERMIT ACL - Test acl rule with protocol = TCP
test_acl_011
No
Verify L3 PERMIT ACL - Test acl rule with protocol = UDP
test_acl_012
No
Verify Drop ACL (IPv6) for matching source IPv6/L4 address and source IPv6L4 port
test_qual_ip6_acl_001
No
Verify Drop ACL (IPv6) for matching destination IPv6/L4 port and source IPv6L4 port
test_qual_ip6_acl_002
No
Verify drop ACL - matching IPv6 params subnet, dst, src ports combined
test_qual_ip6_acl_003
No
Verify PERMIT ACL (IPv6) for matching source IPv6/L4 address and source IPv6L4 port
test_qual_ip6_acl_004
No
Verify Permit ACL (IPv6) for matching destination IPv6/L4 port and source IPv6L4 port
test_qual_ip6_acl_005
No
Verify drop ACL - matching IPv6 params subnet, dst, src ports combined
test_qual_ip6_acl_006
No
Verify whether static ARP entry can be configured
test_arp_003
No
Verify that the DUT will respond to an ARP Request for the SVI interface
test_arp_007
No
Verify whether clear ARP entries works properly
test_arp_011
No
Verify whether ARP entries are flushed after some time
test_arp_012
Yes
Verify eBGP multi-AS config, adjacency, route convergence and data path using router interface
test_bgp_netops_001
No
eBGP Multi-AS Route Convergence and data path using loopback
test_bgp_netops_002
No
BGP Node Drain - Add route-map to remove and restore SPINE node 1 and 2 using Community list
test_bgp_netops_003_004
No
Test Link drain - Apply Route-Map permit
test_bgp_netops_005_006
No
Node drain: with IPv6 Traffic Test Node Drain (Spine 1 and Spine 2) for IPv6 Traffic/Prefixes
test_bgp_netops_007
No
Link drain with IPv6 Traffic Test Link Drain for IPv6 Traffic/Prefixes
test_bgp_netops_008
No
Node drain using prefix-lists
test_bgp_netops_009
No
Test Link Drain with Prefix Lists
test_bgp_netops_010
No
Node drain/restore using AS path prepend list
test_bgp_netops_011_012
No
Link drain using AS path prepend
test_bgp_netops_014
No
MC-LAG L3 validation using port-channel configuration
test_mclag_layer3_steady_state
Yes
MC-LAG L3 validation, Bring down the member link of SPINE01
test_mclag_layer3_member_link_down
Yes
MC-LAG L3 keepalive link down
test_mclag_layer3_keepalive_link_down
Yes
MCLAG-L3 Active Reboot
test_mclag_layer3_active_reboot
Yes
MCLAG-L3 Standby Reboot
test_mclag_layer3_standby_reboot
Yes
Apply QoS with DSCP-0 to TC-0 mapping
test_dscp_0_tc_0
Yes
Apply QoS with DSCP-8 to TC-1 mapping
test_dscp_8_tc_1
Yes
Apply QoS with DSCP-16 to TC-2 mapping
test_dscp_16_tc_2
Yes
Apply QoS with DSCP-24 to TC-3 mapping
test_dscp_24_tc_3
Yes
Apply QoS with DSCP-32 to TC-4
mapping
test_dscp_32_tc_4
Yes
Apply QoS with DSCP-40 to TC-5 mapping
test_dscp_40_tc_5
Yes
Apply QoS with DSCP-48 to TC-6 mapping
test_dscp_48_tc_6
Yes
Apply QoS with DSCP-56 to TC-7 mapping
test_dscp_56_tc_7
Yes
Validate whether the DUT applies QoS using DOT1P-0 to TC-0 mapping
test_dot1p0_tc0
Yes
Validate whether the DUT applies QoS using DOT1P-1 to TC-1 mapping
test_dot1p1_tc1
Yes
Validate whether the DUT applies QoS using DOT1P-2 to TC-2 mapping
test_dot1p2_tc2
Yes
Validate whether the DUT applies QoS using DOT1P-3 to TC-3 mapping
test_dot1p3_tc3
Yes
Validate whether the DUT applies QoS using DOT1P-4 to TC-4 mapping
test_dot1p4_tc4
Yes
Validate whether the DUT applies QoS using DOT1P-5 to TC-5 mapping
test_dot1p5_tc5
Yes
Validate whether the DUT applies QoS using DOT1P-6 to TC-6 mapping
test_dot1p6_tc6
Yes
Validate whether the DUT applies QoS using DOT1P-7 to TC-7 mapping
test_dot1p7_tc7
Yes
Verify basic EVPN VxLAN functionality
test_evpn_vxlan_feature
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 16K routes
test_bgp_unnumbered_evpn_vxlan_inter_vlan_scale_16k
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 32K routes
test_bgp_unnumbered_evpn_vxlan_inter_vlan_scale_32k
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 64K routes
test_bgp_unnumbered_evpn_vxlan_inter_vlan_scale_64k
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 128K routes
test_bgp_unnumbered_evpn_vxlan_inter_vlan_scale_128k
Yes
Configure BGP L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 16K routes
test_bgp_numbered_evpn_vxlan_inter_vlan_scale_16k
Yes
Configure BGP L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 32K routes
test_bgp_numbered_evpn_vxlan_inter_vlan_scale_32k
Yes
Configure BGP L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 64K routes
test_bgp_numbered_evpn_vxlan_inter_vlan_scale_64k
Yes
Configure BGP L3 EVPN-VXLAN and send L3 inter-VLAN traffic for 128K routes
test_bgp_numbered_evpn_vxlan_inter_vlan_scale_128k
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with inter-VLAN
test_bgp_evpn_vxlan_l3_ecmp_with_node_drain
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with inter-VLAN
test_bgp_evpn_vxlan_l3_ecmp_with_link_drain
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with intra-VLAN
test_bgp_evpn_vxlan_with_sag
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 intra-VLAN traffic for 16K routes
test_bgp_unnumbered_evpn_vxlan_intra_vlan_scale_16k
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 intra-VLAN traffic for 32K routes
test_bgp_unnumbered_evpn_vxlan_intra_vlan_scale_32k
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 intra-VLAN traffic for 64K routes
test_bgp_unnumbered_evpn_vxlan_intra_vlan_scale_64k
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 intra-VLAN traffic for 128K routes
test_bgp_unnumbered_evpn_vxlan_intra_vlan_scale_128k
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with intra-VLAN
test_evpn_vxlan_l2_traffic
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with intra-VLAN for 16K routes
test_bgp_evpn_vxlan_l2_intra_vlan_scale_16k
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with intra-VLAN for 32K routes
test_bgp_evpn_vxlan_l2_intra_vlan_scale_32k
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with intra-VLAN for 64K routes
test_bgp_evpn_vxlan_l2_intra_vlan_scale_64k
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with intra-VLAN for 128K routes
test_bgp_evpn_vxlan_l2_intra_vlan_scale_128k
Yes
Configure EVPN-VXLAN and send bidirectional L3 traffic with inter-VLAN
test_evpn_vxlan_l2_inter_vlan
Yes
Configure EVPN-VXLAN and send bidirectional traffic with inter-VLAN for 16K routes
test_bgp_evpn_vxlan_l2_inter_vlan_scale_16k
Yes
Configure EVPN-VXLAN and send bidirectional traffic with inter-VLAN for 32K routes
test_bgp_evpn_vxlan_l2_inter_vlan_scale_32k
Yes
Configure EVPN-VXLAN and send bidirectional traffic with inter-VLAN for 64K routes
test_bgp_evpn_vxlan_l2_inter_vlan_scale_64k
Yes
Configure EVPN-VXLAN and send bidirectional traffic with inter-VLAN for 128K routes
test_bgp_evpn_vxlan_l2_inter_vlan_scale_128k
Yes
Configure BGP unnumbered L3 EVPN-VXLAN and send L3 inter-VLAN traffic with reboot
test_bgp_l3_evpn_vxlan_route_reboot
Yes
QoS DWRR scheduling algorithm with the default configuration
test_qos_dwrr_happy_baseline
Yes
Calculate the congestion buffer size based on the frame size
test_single_queue_congestion_buffer_frame_size
Yes
Buffer test with multiple congested queues
test_buffer_test_multiple_congested_queues
Yes
DHCP relay static MAC functionality
test_dhcp_relay_static_mac_functionality
No
DHCP relay static mac functionality with SVI interface
test_dhcp_relay_svi_functionality
No
DHCP relay functionality after a warm reboot of the relay agent
test_dhcp_relay_warmreboot
No
Restart dhcp relay docker
test_dhcp_relay_restart
No
Verify DHCP relay with the client and server using trunk VLAN configuration
test_dhcp_relay_vlan_tagged
No
DHCP relay server not available
test_dhcp_relay_server_not_available
No
DHCP relay with multiple DHCP servers
test_run_dhcp_relay_multi_server_test
No
Test VRRP steady state configuration
test_vrrp_steady_state_with_reboot
Yes
Test VRRP interface tracking functionality
test_vrrp_interface_tracking
Yes
Test VRRP priority change scenario
test_vrrp_change_priotity
Yes
Test VRRP configuration with non-preemptive mode enabled.
test_vrrp_non_preemptive
Yes
Test VRRP behavior during link down scenario
test_vrrp_link_down
Yes
Test configuration and behavior of multiple VRRP instances on the same VLAN.
test_vrrp_multiple_instance
Yes
Test VRRP functionality in a VRF-aware environment.
test_vrrp_with_vrf_with_reboot
Yes
Last updated
